| Specification |
Fine 5X |
| Operating Weight |
kg |
350 |
| Overall Height (with bracket) |
mm |
1586 |
| Operating Pressure |
bar |
90 - 130 |
| Required Oil Flow |
lpm |
30 - 50 |
| Impact Rate |
bpm |
450 - 900 |
| Tool Diameter |
mm |
68 |
| Suitable Base Machine |
ton |
4 - 8 |
|
Suitable for
TJD 315,TH EX 70, LT PC 71, JCB 3D, JCB 3D SUPER, JCB 4CX, JCB 5D, JCB JS 80, TV TX 760, TV HEMAN 130,LTC 580, LTC 770, LTC 851, BE 70, RW 55, ROBEX 80, |
| Specification |
Fine 6X |
| Operating Weight |
kg |
405 |
| Overall Height (with bracket) |
mm |
1870 |
| Operating Pressure |
bar |
90 - 130 |
| Required Oil Flow |
lpm |
45 - 90 |
| Impact Rate |
bpm |
400 - 800 |
| Tool Diameter |
mm |
72 |
| Suitable Base Machine |
ton |
5 - 8 |
|
Suitable for
TJD 315,TH EX 70, LT PC 71, JCB 3D, JCB 3D SUPER, JCB 4CX, JCB 5D, JCB JS 80,TV TX 760, TV HEMAN 130,LTC 580, LTC 770, LTC 851, BE 70, RW 55, ROBEX 80 |
| Specification |
Fine 10X |
| Operating Weight |
kg |
870 |
| Overall Height (with bracket) |
mm |
2338 |
| Operating Pressure |
bar |
120 - 150 |
| Required Oil Flow |
lpm |
80 - 110 |
| Impact Rate |
bpm |
450 - 800 |
| Tool Diameter |
mm |
100 |
| Suitable Base Machine |
ton |
9 - 14 |
|
Suitable for
TH EX 110, H EX 120 Z, LT CK 72, LT PC 130, V EC 140, JCB JS 140, BE 100, ROBEX 110, CAT 311 SK 135 |
| Specification |
Fine 12X |
| Operating Weight |
kg |
920 |
| Overall Height (with bracket) |
mm |
2400 |
| Operating Pressure |
bar |
150 - 180 |
| Required Oil Flow |
lpm |
90 - 120 |
| Impact Rate |
bpm |
400 - 900 |
| Tool Diameter |
mm |
110 |
| Suitable Base Machine |
ton |
12 - 14 |
|
Suitable for
TH EX 110, H EX 120 Z, LT CK 72, LT PC 130, V EC 140, JCB JS 140, BE 100, ROBEX 110, CAT 311 SK 135 |
| Specification |
Fine 21X Plus |
| Operating Weight |
kg |
1660 |
| Overall Height (with bracket) |
mm |
2500 |
| Operating Pressure |
bar |
160 - 180 |
| Required Oil Flow |
lpm |
140 - 160 |
| Impact Rate |
bpm |
350 - 600 |
| Tool Diameter |
mm |
135 |
| Suitable Base Machine |
ton |
16 - 22 |
|
Suitable for
TH EX 200, H EX 200 Z, TH EX 210, LT CK 90, PC 200, PC 210, V EC 210, V EC 240, JCB JS 200, JCB JS 210, BE 220, ROBEX 160, ROBEX 210, ROBEX 250, CAT 320, CAT 325, SK 210. |
| Specification |
Fine 23X Plus |
| Operating Weight |
kg |
1880 |
| Overall Height (with bracket) |
mm |
2707 |
| Operating Pressure |
bar |
160 - 180 |
| Required Oil Flow |
lpm |
150 - 180 |
| Impact Rate |
bpm |
350 - 550 |
| Tool Diameter |
mm |
140 |
| Suitable Base Machine |
ton |
18 - 28 |
|
Suitable for
TH EX 200, H EX 200 Z, TH EX 210, LT CK 90, PC 200, PC 210, V EC 210, V EC 240, JCB JS 200, JCB JS 210, BE 220, ROBEX 210, ROBEX 250, CAT 320, CAT 325, SK 210. |
| Specification |
Fine 37X |
| Operating Weight |
kg |
2350 |
| Overall Height (with bracket) |
mm |
3100 |
| Operating Pressure |
bar |
160 - 180 |
| Required Oil Flow |
lpm |
180 - 220 |
| Impact Rate |
bpm |
300 - 500 |
| Tool Diameter |
mm |
155 |
| Suitable Base Machine |
ton |
30 - 38 |
|
Suitable for
H EX 270 Z, TH EX 300, H EX 350 Z, CK 170, PC 300, JCB JS 330, BE 300, ROBEX 290, ROBEX 320, VEC 290, CAT 325, CAT 330, SK 350. |
| Specification |
Fine 45X |
| Operating Weight |
kg |
3280 |
| Overall Height (with bracket) |
mm |
3258 |
| Operating Pressure |
bar |
160 - 180 |
| Required Oil Flow |
lpm |
190 - 250 |
| Impact Rate |
bpm |
300 - 600 |
| Tool Diameter |
mm |
160 |
| Suitable Base Machine |
ton |
40 - 49 |
|
Suitable for
TH EX 400, PC 400, JCB JS 330, BE 300, ROBEX 390 |
| Specification |
Fine 50X |
| Operating Weight |
kg |
4100 |
| Overall Height (with bracket) |
mm |
3726 |
| Operating Pressure |
bar |
160 - 180 |
| Required Oil Flow |
lpm |
250 - 310 |
| Impact Rate |
bpm |
250 - 450 |
| Tool Diameter |
mm |
175 |
| Suitable Base Machine |
ton |
50 - 65 |
|
Suitable for
TH EX 600, CK 300, PC 600, V EC 460, ROBEX 450, ROBEX 600, CAT 345, SK 480. |
|
