Forward Standard Plate Compactor
fi – Forward Standard Plate offers excellent performance for compacting granular soils & asphalt with durable vibrator & structural engineer. |
 |
| Specification |
| Model |
FPC-
60 |
FPC-
80 |
FPC-
80J |
FPC-
80RH |
FPC-
90WT |
FPC-
100 |
FPC-
100WT |
FPC-90RHD |
| Weight (kg) |
69-72 |
89-92 |
87-90 |
82-85 |
83-104 |
105-108 |
111-130 |
95-98 |
Operating Size
(W*L*H)
(mm) |
375*
960*
897 |
415*
1074*
827 |
450*
1013*
933 |
460*
930* 1050 |
405*
960*
897 |
500*
915*
985 |
500*
1146*
1000 |
490*
930*
1050 |
Compacting Size
(W*L)
(mm) |
375*
336 |
415*404 |
450*
461 |
460*
340 |
405*
336 |
500*
461 |
500*
376 |
490*
340 |
| Centrifugal Force
(kN) |
11.1 (1131kgf) |
17.7 (1805kgf) |
19.6 (2000kgf) |
19.4 (1978kgf) |
14 (1428kgf) |
23.5 (2400kgf) |
19.6 (2400kgf) |
19.4 (1978kgf) |
| Vibration Frequency (Hz) |
95 |
106 |
106 |
108 |
95 |
106 |
106 |
108 |
| Travel Speed (m/min) |
20–25 |
20–25 |
20–25 |
28 |
20–25 |
20–25 |
20–25 |
26 |
| Engine |
Honda GX – 160 (5.5 hp, 4.0 kW), Robin EX – 17D (6.0 hp, 4.2 kW) (Petrol Operated) Lombardini 15LD225 (Diesel Operated) |
|
Forward Premium Plate Compactor
fi – Forward Premium Plate is designed for plate operator. Ductile Iron plate shows high strength & efficiency for compacting. And low vibration of the handle with double shock-mounted design ensures the comfortable work by reducing operator's fatigue.
| Specification |
|
|
|
| Model |
FPC-300 |
FPC-400 |
FPC-500 |
| Weight (kg) (Without Water) |
50.5 |
76 |
91 |
| Operating Size (W*L*H)(mm) |
350 X 650 X 925 |
415 X 650 X 925 |
400 X 1138 X 937 |
| Compacting Size (L*W)(mm) |
344.8 X 300 |
400 X 398.4 |
592X 500 |
| Centrifugal Force (kN) |
10 (1000kgf) |
15.3 (1530kgf) |
15.0 (1500kgf) |
| Vibration Frequency (Hz) |
100 |
100 |
100 |
| Travel Speed (m/min) |
22 – 25 |
20 – 25 |
22 – 25 |
| Engine |
Honda GX 100 |
Honda GX 160 (5.5hp, 4.0kW) |
Reversible Plate Compactor
fi - Reversible Plate is ideal for foundation work, cohesive soils & trenches. It offers forward, backward & on-spot compaction by hydraulic system & easy to change the direction with single control lever.
| Specification |
| Model |
FPC-835R |
FPC-940R |
FPC-1545R |
FPC-2045RD |
| Weight (kg) |
85-88 |
92-95 |
150-153 |
170-173 |
| Operating Size (W*L*H) (mm) |
350*1090* 1090 |
400*1090* 1090 |
430*1231* 1045 |
430*1231* 1045 |
| Compacting Size (W*L) (mm) |
350*303 |
400*303 |
430*330 |
430*330 |
| Centrifugal Force (kN) |
16.5 (1682kgf) |
18 (1835kgf) |
29.4 (3000kgf) |
29.4 (3000 kgf) |
| Vibration Frequency (vpm) |
6000 (100 Hz) |
6000 (100 Hz) |
5600 (93 Hz) |
5600 (93 Hz) |
| Travel Speed (m/min) |
28 |
25 |
23 |
23 |
| Engine |
Honda GX – 160 (5.5hp, 4.0kW) (Petrol Operated) |
Lombardini 15LD225 (Diesel Operated) |
| * Other engines are available according to customers request / Specifications may change due to continuous product development. |
| Specification |
FIC - 14 |
FIC-20G |
FIC-30 |
| Weight (kg) |
75 |
150 |
350 |
| Operation size(WxLxH) |
510*940*825 |
610*1210*1020 |
700*1432*975 |
| Blade capacity (inch) |
10-14 |
14-20 |
14-30 |
| Maximum cutting depth (mm) |
120(4.7 in) |
180 (7.0 in) |
300 (11.8 in) |
| Water tank capacity (I) |
18 |
39 |
outside |
| Arbor diameter (mm) |
27 or 25.4 mm (as required) |
| Depth adjustment mechanism |
Handle Rotation |
Handle Rotation |
Hydraulic |
| Driver mechanism |
Manual Push |
Gear Type |
Hydrostatic transmission |
| Engine |
Honda GX-160, GX-270 (Petrol) |
Honda GX-390, GX-630 (Petrol) |
Kolher PA-CH740 (Diesel) |
| Specification |
FIR-70 |
| Weight (kg) |
72 |
| Operation size(W*L*H) (mm) |
415 x 720 x 1043 |
| Shoe size(W*L) (mm) |
340 X 285 (13X11) |
| Blows per minute |
680-710 |
| Travel speed (m/min) |
10-15 |
| Stroke Length (mm) |
upto 85 |
| Engine |
Robin EH 12-2D |
| Engine type |
Air cooled 4 - cycle gasoline engine |
| Engine Power (hp) |
4.0 hp |
| Fuel tank capacity (I) |
2.5 |
| Specification |
FMT 24 |
FMT 36 |
FMT 46 |
| Weight (kg) |
62 |
95 |
139 |
| Operation size(WxLxH) |
680*1500*1000 |
1000*1700*1000 |
1300*1950*850 |
| Working Blade Diameter (mm) |
609 (24") |
914 (36") |
1168 (46") |
| No. of Blades |
4 |
4 |
4 |
| Pitch Range |
0 - 15° |
0 - 15° |
0 - 15° |
| Trowel Speed (rpm) |
75 - 120 |
60 - 130 |
60 - 130 |
| Efficiency (m2/hr) |
100 |
200 |
280 |
| Engine |
Honda GX 160 |
Honda GX 270 |
Drive Unit For High Cycle Eccentric Vibrator
| Specification |
| FEVM |
|
| Voltage (AC) (V) |
230 |
| Weight (kg) |
5.8 |
| Overall Size (mm) |
350 * 160 * 230 |
| Power (hp) |
2.1 |
| Current (A) |
7 |
| Frequency (Hz) |
50/60 |
| Phase |
Single |
| Motor Type |
Universal Electric Motor |
| Unloaded Speed (rpm) |
17,500 |
| Loaded Speed (rpm) |
12,000 |
| Connection to flexible shaft |
Square Socket |
| Specification |
| FEVM |
FEV – 28 |
FEV – 35 |
FEV – 40 |
FEV – 45 |
FEV –55 |
| Weight (4M) (kg) |
6.3 |
7 |
7.5 |
8 |
10 |
| Head Diameter (mm) |
28 |
35 |
40 |
45 |
55 |
| Head Weight (kg) |
1.3 |
2 |
2.7 |
3.4 |
4.7 |
| Head Length (mm) |
390 |
390 |
400 |
400 |
415 |
| Centrifugal Force (kN) |
1.1 |
2.3 |
3.5 |
5.9 |
9.0 |
| Vibration Frequency (vpm) |
12000 ± 2000 (200 ± 33 Hz) |
| Vibration Amplitude (mm) |
1.46 |
2.26 |
2.45 |
2.82 |
3.39 |
| Flexible Shaft length (m) |
Standard 4.0m (13.1ft), Maximum 6.0m (20.0ft) |
| Drive Unit |
Single Phase Universal Electric Motor (115 V, 230V) / Honda GX – 160 Petrol Driven Engine |
Pendulum Vibrator
fi – Pendulum Vibrator is widely used for concrete consolidation and air removal in various construction sites & ensures stronger and quality concrete with clean surface.
| Specification |
| Model |
FIV-32 |
FIV-45 |
FIV-60 |
| Weight (kg) |
13 |
15 |
22 |
| Head Diameter (mm) |
32 |
45 |
60 |
| Head Length (mm) |
445 |
445 |
545 |
| Speed of flexible shaft (rpm) |
3,000-3,600 |
|
|
| Vibration Frequency (vpm) |
9,000-12,000 (150Hz-200Hz) |
| Vibration Amplitude (mm) |
1.4 |
1.6 |
2.4 |
| Flexible Shaft length (m) |
Standard 6.0m (19.7ft), Maximum 7m (27.5ft) |
| Drive Unit |
Electric - Single Phase 1.0hp, 2.0hp / Petrol - Honda GX 120, 160, 200 |
Handy Vibrator
fi – Handy Vibrator is portable and multi purpose high cycle eccentric vibrator. It is lightweight and easy to handle so it can be useful everywhere.
| Specification |
| Model |
FIV-28 |
FIV-32 |
| Frequency (vpm) |
12000 – 14000 |
12000 – 14000 |
| Vibration Amplitude (mm) |
1.1 |
1.1 |
| Head (Dia*Length) (mm) |
28 * 190 |
32 * 190 |
| Total Length (m) |
1.0 – 1.5 |
1.0 – 1.5 |
| Weight (kg) |
4.2 – 4.9 |
4.2 – 4.9 |
| Power (W) |
480 |
480 |
| Specification |
| Model |
FSV-35 |
| Weight (kg) |
15 |
| Operating Size (W*L*H) (mm) |
770*900*1000 |
| Vibration Frequency (vpm) |
7000 (117Hz) |
| Blade Size (ft) |
8 – 14 (2.44m – 4.27m) |
| Engine |
Honda GX – 35 |
| Engine Type |
Air cooled 4-cycle gasoline engine |
| Engine Power (hp) |
1.6 hp |
| Fuel Tank Capacity (l) |
0.65 l |
|
|
